MAC-D2 / D4

Description

2/4 Doors Card based Access Control System

• MAC-D2: Manage 2 doors 2 ways
MAC-D4 : Manage 4 doors 1 way
• No. of User Cards Storage : 20,000
• No. of Transaction Storage : 60,000 logs
• Communications Interface : TCP/IP, Wiegand
• Built in Web-Server, Accessible via TCP/IP
• Authorised Settings : Time Setting / Zone Setting / Group Setting / Holiday Setting
• Support Wiegand reader : 26 / 34 / 66 Bit format
• Max. Range for Wiegand reader : 80 Meters
• Anti-Pass back & Inter-locking function for people & visitor management at different areas Jail, Military, Bank... etc
• Fire Alarm Connection : Yes
• Easy to Upgrade via Internet Web-Server
• Online fast registry
• Power Requirement : DC 9-24V
• Suggested Power Specs. : 1.5A (02) & 2A (04)
• Operating Temperature : 00 — 55' C
• Operating Humidity : 50/0 — 80%, RH
• Dimension : 200 " 114 " 27 mm
• Optional : Metal Enclosure with Power SMPS & LED Connection
